45
3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip
Extended Video Modes with 2 MB DRAM
71h 111h graphics 640 x 480 65,536 60 31.5 25.175
71h 111h graphics 640 x 480 65,536 72 37.5 31.500
71h 111h graphics 640 x 480 65,536 75 37.5 31.500
71h 111h graphics 640 x 480 65,536 85 45 36.000
72h 112h graphics 640 x 480 16.7 M 60 31.5 25.175
72h 112h graphics 640 x 480 16.7 M 72 37.9 31.500
72h 112h graphics 640 x 480 16.7 M 75 37.5 31.500
72h 112h graphics 640 x 480 16.7 M 85 45 36.000
73h 113h graphics 800 x 600 32,768 60 37.9 40.000
73h 113h graphics 800 x 600 32,768 72 48.1 50.000
73h 113h graphics 800 x 600 32,768 75 46.8 49.500
73h 113h graphics 800 x 600 32,768 85 53.6 57.000
74h 114h graphics 800 x 600 65,536 60 37.9 40.000
74h 114h graphics 800 x 600 65,536 72 48.1 50.000
74h 114h graphics 800 x 600 65,536 75 46.8 49.500
74h 114h graphics 800 x 600 65,536 85 53.6 57.000
Extended
Mode No.
VESA
Mode No.
Interface
Type
Resolution
No. of
Colors
Vertical
Refresh
(Hz)
Horizontal
Refresh
(kHz)
Dot Clock
(MHz)
6Fh 107h graphics 1280 x 1024 256 60 65 55.000
6Fh 107h graphics 1280 x 1024 256 72 77.7 65.000
6Fh 107h graphics 1280 x 1024 256 75 79.5 67.000
75h 115h graphics 800 x 600 16.7 M 60 37.9 40.000
75h 115h graphics 800 x 600 16.7 M 72 41.8 50.000
75h 115h graphics 800 x 600 16.7 M 75 46.8 49.500
75h 115h graphics 800 x 600 16.7 M 85 53.6 57.000
76h 116h graphics 1024 x 768 32,768 60 48.9 65.000
76h 116h graphics 1024 x 768 32,768 70 56.5 75.000
76h 116h graphics 1024 x 768 32,768 75 60.2 80.000
76h 116h graphics 1024 x 768 32,768 85 68.7 95.000
77h 117h graphics 1024 x 768 65,536 60 48.9 65.000
77h 117h graphics 1024 x 768 65,536 70 56.5 75.000
77h 117h graphics 1024 x 768 65,536 75 60.2 80.000
77h 117h graphics 1024 x 768 65,536 85 68.7 95.000
7Ch 120h graphics 1600 x 1200 256 48.5i 62.00 67.000
Extended
Mode No.
VESA
Mode No.
Interface
Type
Resolution
No. of
Colors
Vertical
Refresh
(Hz)
Horizontal
Refresh
(kHz)
Dot Clock
(MHz)
