3–6 Maintenance and Service Guide
Illustrated parts catalog
6-cell, 55-Wh, 2.55-Ah Li-ion battery 511872-001
6-cell, 47-Wh, 2.2-Ah Li-ion battery 484170-001
3-cell, 47-Wh, 4.4-Ah Li-ion battery 516915-001
(17) Optical drive (includes bezel and bracket)
■ DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 511880-001
■ Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive 511882-001
(18) TV tuner module
✎
The TV tuner module spare part kit does not include a TV tuner module cable. The TV tuner module cable is
included in the Cable Kit, spare part number 512832-001.
DVB-T TV tuner module 482899-003
DVB-T/ANG TV tuner module 482899-002
ATSC/NTSC/QAM hybrid TV tuner module 482899-001
TV tuner external antenna cable (not illustrated)
With F-PAL jack 482900-001
With PAL jack 482900-002
(19) RTC battery 449729-001
(20) Memory modules, PC3, 1066-MHz FSB
■ 4096-MB 579156-001
■ 2048-MB 579155-001
■ 1024-MB 579154-001
(21) Modem module
✎
The modem module spare part kit does not include a modem module cable. The modem module cable is
included in the Cable Kit, spare part number 512832-001.
For use in all countries and regions except Australia and New Zealand 510100-001
For use only in Australia and New Zealand 510100-011
(22) WLAN module
Broadcom 4312 802.11b/g WLAN module:
■ For use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam,
Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States
504593-003
Item Description Spare Part Number
