Keyboard
Description Spare part number
For use in French Canada 619433-121
For use in Japan 619433-291
For use in the South Korea 619433-AD1
For use in Taiwan 619433-AB1
For use in Thailand 619433-281
For use in the United States 619433-001
For use in French Canada with backlight 619434-121
For use in Japan with backlight 619434-291
For use in South Korea with backlight 619434-AD1
For use in Taiwan with backlight 619434-AB1
For use in Thailand with backlight 619434-281
For use in the United States with backlight 619434-001
Before removing the keyboard:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn on
the computer, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC
outlet and then disconnecting the AC adapter from the computer.
4. Remove the battery (see
Battery on page 34).
5. Remove the hard drive (see
Hard drive on page 36).
6. Remove the Memory Module compartment cover (see
Memory module on page 39).
Remove the keyboard:
1. Turn the computer upside down with the front toward you.
2. Remove the three Phillips PM2.5×5.0 screws that secure the keyboard to the computer.
42 Chapter 4 Removal and replacement procedures
