Mini bus bars
Bus boxes
Scalable bus bars
Dual power input kit for mini bus bar option
HP BladeSystem p-Class power distribution (only required with 3U power enclosure)
HP BladeSystem p-Class power distribution (only required with 3U power enclosure)HP BladeSystem p-Class power distribution (only required with 3U power enclosure)
HP BladeSystem p-Class power distribution (only required with 3U power enclosure)
Configuration Steps
Configuration StepsConfiguration Steps
Configuration Steps
For a complete HP ProLiant BL30p server blade solution, do the following:
Select desired model, configuration and quantity of HP ProLiant BL30p server blades
PLUS
PLUSPLUS
PLUS
Determine how many HP BladeSystem p-Class blade sleeves are required. Each p-Class blade sleeve holds two HP ProLiant
BL30p server blades and one server blade enclosure holds up to eight sleeves.
PLUS
PLUSPLUS
PLUS
Determine how many HP BladeSystem p-Class Enhanced Server Blade Enclosures are required. Each enhanced server blade
enclosure can hold up to 16 HP ProLiant BL30p server blades.
NOTE:
NOTE: NOTE:
NOTE:
HP BladeSystem p-Class enhanced server blade enclosures are required to support HP ProLiant BL30p server blades.
Enhanced server blade enclosures can be purchased with licenses for Rapid Deployment Pack:
HP BladeSystem p-Class enhanced server blade enclosure with 8 Rapid Deployment Pack licenses (281404-B22)
Or
HP BladeSystem p-Class enhanced server blade enclosure with Rapid Deployment Pack trial (243564-B22)
Or
HP BladeSystem p-Class server blade enclosure with the HP BladeSystem Management Suite which is delivered in a
convenient to purchase pack that includes a single copy of Systems Insight Manager (SIM) and 8 licenses for each of the
following products: Rapid Deployment Pack (RDP) Performance Management Pack (PMP) and the Vulnerability and Patch
Management Pack (VPM). (380625-B22)
PLUS
PLUSPLUS
PLUS
QuickSpecs
HP ProLiant BL30p Server Blade
HP ProLiant BL30p Server BladeHP ProLiant BL30p Server Blade
HP ProLiant BL30p Server Blade
Overview
DA - 11958 Worldwide — Version 19 — August 15, 2005
Page 5
