5.
Remove the mass storage device bracket (2). The mass storage device bracket and screws are
included in the Hard Drive Hardware Kit, spare part number 608373-001.
NOTE: Select computer models are equipped with an mSATA solid-state drive. This drive is
located beneath the hard drive. If it is necessary to replace the mSATA solid-state drive, follow
these steps:
6. Remove the hard drive.
7. Remove the two Phillips PM2.0×2.83 screws that secure the mSATA solid-state drive to the
system board. (The mSATA solid-state drive tilts up.)
40 Chapter 4 Removal and replacement procedures
