ThinConnect4 <141>
11.1 Product Specifications
Hardware Specification
Category Item Specifications
Serial Port Port No. 2 ports
Interface V.24/V.28 (RS-232C)
Connector Type 9pin D-sub (S1) / 25pin D-sub (S2)
DTE 1.2 /2.4 /4.8 /7.2 /9.6 /14.4 /19.2 /28.8 /38.4
57.6 /115.2 /230.4 /460.8 (Kbps)
Flow Control Hardware Control (RTS/CTS)
LAN Port Port No. 4 ports
Interface IEEE802.3/ISO8802-3 CSMA/CD 10BASE-T
Connector Type RJ-45
Power AC Adapter INPUT : AC 100/120/230/240V 50/60 Hz
OUTPUT: AC 9V 1000 mA
Outlook Dimension 131 (W) x 191 (D) x 29 (H) mm
Net Weight 400g
Environment Operating
Temperature
0 to 40C
Operating humidity 25 to 85%
