FENIX IMVICO
TK14 OPERATION MANUAL
35/65
GS B
n
[Name] Turn white/black reverse printing mode
[Format] ASCII GS B
n
Hex 1D 42
n
Decimal 29 66
n
[Range] 0
≤
n
≤
255
[Description] Turns on or off white/black reverse printing mode.
When the LSB of
n i
s 0, white/black reverse mode is turned off.
When the LSB of
n
is 1, white/black reverse mode is turned on.
[Notes]
•
Only the lowest bit of
n
is valid.
•
When white/black reverse printing mode is on, it also applied to character spacing set
by
ESC SP
.
•
This command does not affect bit image, user-defined bit image, bar code and HRI
characters.
•
This command does not affect the space between lines.
•
White/black reverse mode has a higher priority than underline mode. Even if underline
mode is on, it is disabled (but not cancelled) when white/black reverse mode is
selected.
[Default]
n
= 0
ESC J
n
[Name] Print and feed paper
[Format] ASCII ESC J
n
Hex 1B 4A
n
Decimal 27 74
n
[Range] <00>H
≤
n
≤
<FF>H
[Description] Prints the data in the print buffer and feeds the paper [
n
x 0.125 mm (0.0049”)].
[Notes]
•
After printing is completed, this command sets the print starting position to the
beginning of the line.
•
The paper feed amount set by this command does not affect the values set by
ESC 2
or
ESC 3
.
•
The printer uses the vertical motion unit
(
y).
ESC M
n
[Name] Select character font
[Format] ASCII ESC M
n
Hex 1B 4D
n
Decimal 27 77
n
[Range]
n
= <00>H, <01>H
[Description] Selects the character font.
n
Function
<00>H Character Font A (12 x 24) selected
<01>H Character Font B (8 x 16) selected
[Notes]
•
ESC !
can also select character font types. However the setting of the last received
command is effective.
•
This command must be sent at the beginning of a line. If it is sent in the middle of a line,
all previous data in the print buffer is printed and the ticket is placed at the beginning of
the next line.
[Reference]
ESC !, APPENDIX A
