FAN STYLES > TRADITIONAL
Ceiling Drop Dimensions
Features
Specs
16
The elegant Cordova features European styling
with an array of blade and light combinations
Cordova
®
Heavy-Duty, 3 Speed Reversible
Motor
2" and 6" Downrods (Included)
Limited Lifetime Warranty
Blades Sold Separately
Light Kit Adaptable (Optional)
Both TCS Controls Available (Optional)
Energy Star Qualified
Blade Sweep Opt. 44", 52", 54", 56"
Number of Blades 5
Blade Pitch 14˚
Motor Size (MM) 188 x 15
AMPS (HI Speed) 0.7
Watts (HI Speed) 78
RPM (HI-MED-LOW) 210-120-78
Shipping Wt. (lbs.) 19
CU. FT. in Carton 1.94
Airflow*
(Cubic Feet Per Minute)
6,419
Electricity Use* 78 Watts
Airflow Efficiency*
(Cubic Feet Per Minute
Per Watt)
82
B
E
D
C
C
A
A: 2" DR - 12.5" B: 2" DR - 9.0"
A: 6" DR - 16.5" B: 6" DR - 13.0"
C: 13.0" D: 5.125"
E: 4.75"
DR: Downrod
Aged Bronze Cordova with 56" Custom Carved Chamberlain
Oak Blades
Model-Finish CV52AG
Blade-Finish B556C-CH2
Light-Finish Not Shown
“Compare: 36" to 48" ceiling fans have airflow efficiencies
ranging from approximately 71 to 86 cubic feet per minute
per watt at high speed.”
“Compare: 49" to 60" ceiling fans have airflow efficiencies
ranging from approximately 51 to 176 cubic feet per
minute per watt at high speed.”
