Chapter 14 Configuring Web-Based Authentication
Information About Configuring Web-Based Authentication
Default Web-Based Authentication Settings
Configuring Switch-to-RADIUS-Server Communication
RADIUS security servers identification:
• Host name
• Host IP address
• Host name and specific UDP port numbers
• IP address and specific UDP port numbers
The combination of the IP address and UDP port number creates a unique identifier, that enables
RADIUS requests to be sent to multiple UDP ports on a server at the same IP address. If two different
host entries on the same RADIUS server are configured for the same service (for example,
authentication) the second host entry that is configured functions as the failover backup to the first one.
The RADIUS host entries are chosen in the order that they were configured.
Table 14-1 Default Web-Based Authentication Settings
Feature Default Settings
AAA Disabled
RADIUS server
• IP address
• UDP authentication port
• Key
• None specified
• 1812
• None specified
Default value of inactivity timeout 3600 seconds
Inactivity timeout Enabled
