Specifications
Rev 46514-20100202 English 19
Item Part Number Description Qty
53 ST188FD-1180121 Spark Arrester Assembly 1
54 ST188FD-1100010-88 Spark Arrester Cover 1
55 GB93 5 Lock Washer ø5 2
56 GB818 M5×14 Flange Bolt M5×15 2
57 ST02FD-02100008 Brush Support Plate 1
58 ST02FD-05212002 Grommet 1
59 ST02FD-05202003 Conduit 1
60 ST02FD-05212001 Grommet 1
61 GB823 M5×38 Screw M5×38 3
62 GB848 5 Washer ø5 3
63 OV01-00000000-1 Transition 1
64 GB6177 M4 Nut M4 5
65 GB818 M4×14 Screw M4×14 1
66 ST02FD-05202002 Control Box 1
67 GB5783 M6×22
Bolt M6×22 1
68 GB97.1 6
Washer ø6 2
69 GB93 6
Lock Washer ø6 2
70 GB6175 M6
Nut M6 2
71
ST02FD-05010703
Bolt M5×12 4
72 ST02FD-05502024 5-20R AC Receptacle 1
73 ST02FD-05502029 RV Receptacle 1
74 ST02FD-05702008 Voltage Selector 1
75 GB818 M4×14 Screw M4×10 6
76 ST02FD-05502020 Receptacle L14-30R 1
77 ST02FD-05602010-D Volt Meter 1
78 ST02FD-05302001-L15 15 Amp Circuit Breaker 2
79 2A66 Control Panel 1
80 ST02FD-05702002 Engine Switch 1
