Wireless Broadband Router
A02-RB-W54 Pag. 53
• Protocol: Select the protocol TCP or UDP that can be used to access the
application, the “*” is meaning to both of TCP and UDP protocols.
• Port Range: Type the port range that can be used to access the
application in the text boxes.
Incoming: Defines which incoming communications users are permitted to
connect with.
• Protocol: Select the protocol TCP or UDP that can be used by the
incoming communication, the “*” is meaning to both of TCP and UDP
protocols.
• Port: Type the port number that can be used for the incoming
communication.
Add: Click to add the special application profile to the table at the bottom of the
screen.
Update: Click to update information for the special application if user have
selected a list item and have made changes.
Delete: Select a list item and click Delete to remove the item from the list.
Clear: Click to erase all fields and enter new information.
3.7.4 DMZ
The DMZ function enables users to create a DMZ for those computers that cannot
access Internet applications properly through the Wireless Broadband Router and
associated security settings.
Enable: Click to enable or disable the DMZ.
DMZ Host IP: Type a host IP address for the DMZ. The computer with this IP
address acts as a DMZ host with unlimited Internet access.
Click Apply to save.
