Chapter 9 Define a function block diagram routine
178 Rockwell Automation Publication 1756-RM084S-EN-P - March 2015
Function block instruction reference manuals
Instruction Type Resource
Basic, sequential instruction
Logix5000 Controllers General Instructions Set Reference Manual, publication 1756-RM003.
Process control or drives
instruction
Logix5000 Controllers Advanced Process Control and Drives Instruction Set Reference Manual, publication1756-RM006.
Motion instruction Logix5000 Controllers Motion Instructions Reference Manual, publication MOTION RM002.
Function block instructions
Instruction Default Operand and VisiblePins formats (components within the Block structure)
ABS Operand := ABS_01,
VisiblePins := "Source, Destination")
ACS Operand := ACS_01,
VisiblePins := "Source, Destination")
ADD Operand := ADD_01,
VisiblePins := "SourceA, SourceB, Destination")
ALM Operand := ALM_01,
VisiblePins := "In, HHAlarm, HAlarm, LAlarm, LLAlarm, ROCPosAlarm, ROCNegAlarm")
ALMA Operand := ALMA_01,
VisiblePins := "In, HHInAlarm, HInAlarm, LInAlarm, LLInAlarm, ROCPosInAlarm, ROCNegInAlarm, HHAcked, HAcked, LAcked, LLAcked, ROCPosAcked,
ROCNegAcked, Suppressed, Disabled")
ALMD Operand := ALMD_01,
VisiblePins := "In, InAlarm, Acked, Suppressed, Disabled")
AND Operand := AND_01,
VisiblePins := "SourceA, SourceB, Destination")
ASN Operand := ASN_01,
VisiblePins := "Source, Destination")
ATN Operand := ATN_01,
VisiblePins := "Source, Destination")
BAND Operand := BAND_01,
VisiblePins := "In1, In2, In3, In4, Out")
BNOT Operand := BNOT_01,
VisiblePins := "In, Out")
BOR Operand := BOR_01,
VisiblePins := "In1, In2, In3, In4, Out")
BTDT Operand := BTDT_01,
VisiblePins := "Source, SourceBit, Length, DestBit, Target, Dest")
BXOR Operand := BXOR_01,
VisiblePins := "In1, In2, Out")
COS Operand := COS_01,
VisiblePins := "Source, Dest")
CTUD Operand := CTUD_01,
VisiblePins := "CUEnable, CDEnable, PRE, Reset, ACC, DN")
