2 Chapter 1
On-Board Graphic solution
• NV GT218-ION with 512MB VRAM
• 1 D-Sub port on rear
• 1 HDMI port on rear
• Dual view support
Hard disk
• Support up to one SATA ports
• 2.5"
• Capacity and models are listed on FRU
Optical disk
• None
Serial ATA controller
• Slot Type: SATA connector
• Slot Quantity: 1
• Storage Type support: HDD
Audio
• Chip: vendor propose (Realtek 662)
• Connectors support:
• Audio jacks color coding: should meet Microsoft Windows Logo Program Device Requirements:
Audio-0002
• Front 2 jack follow HD audio definition
• Add HD de-pop CKT
LAN
• Controller: Proposed by vender
• Port: 1 x RJ45 rear port for Gigabit Ethernet
• Design Criteria:
• Should be worked under 10/100/1000Mbs environment
• Reserved disable function on both hardware & BIOS side. Default is enabled
• Support network PXE boot
USB ports
• Controller: Intel NM10
• Ports Quantity: 6 for aPluto
• 4 back panel ports
• 2 ports for front (Daughter board)
• Connector Pin: standard Intel FPIO pin definition
• USB 2.0/1.1Data transfer rate support
Extension slot
• Support one Mini PCIe slot
