6

4 Attach the bridge with bracket to the plate already fixed to the pole.

5 Use the included nuts to secure the wireless bridge to the pole bracket. Note that the

wireless bridge tilt angle may need to be adjusted during the antenna alignment process.

Be sure to take account of the antenna polarization direction; all antennas in a link must be

mounted with the same polarization.

Using the Wall-Mounting Bracket

Perform the following steps to mount the unit to a wall using the wall-mounting bracket:

1 Always attach the bracket to a wall with the flat side flush against the wall (see following

figure).

CAUTION: The wall-mounting bracket does not allow the bridge’s integrated antenna

to be aligned. It is intended for deployment using a 5.0 GHz external antenna.
