Samsung Model DV316HEC Clothes Dryer User Manual



B-3 SAMSUNG Dryer Owner’s Instructions
7. Select Cycle Option
Adjust Time – Time can be added or subtracted from the automatically set times in the Manual
Dry cycles (Time Dry, Freshen Up, Delicates, Wrinkle Release, or Air Fluff cycles).
To add or subtract time from the cycle, press the Adjust Time arrow pad up or down until the
desired time is displayed.
My Cycle – Choose your favorite cycle including cycle, temp, dry level option, etc. (See page B4 for
detail.)
Rack Dry – Rack Dry is available at Time Dry cycle. Temperature will be set only to Extra Low. (See
page B5 for detail.)
8. Cycle Selector
To select a cycle, rotate the Cycle Selector dial to the desired cycle.
The indicator light by the cycle name will illuminate. The Normal, Heavy Duty, Towels, Perm Press
and Delicates cycles are Sensor Dry cycles.
Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the selected
dryness level (very dry to damp dry) is reached.
Normal – Dry loads such as cotton, underwear, and linens use this cycle to get various levels of
heat for drying.
Heavy Duty – Use this cycle to get high heat for heavy fabrics such as jeans, corduroys, or work
clothes.
Towels – Dry loads such as bath towels.
Perm Press – Dry wrinkle-free cottons, synthetic fabrics, knits, and permanent press fabrics
automatically. The cycle minimizes wrinkling by providing a longer unheated cool-down period at
the end of the cycle.
Delicates – The Delicates cycle is designed to dry heat-sensitive items at a low drying temperature.
Freshen Up – This cycle removes odors and freshens garments.
Time Dry – Time Dry allows you to select the desired cycle time in minutes.
Turn the Cycle Selector dial to Time Dry, then press the Adjust Time up arrow to set the drying time.
Press the arrow repeatedly to scroll through the time settings.
Wrinkle Release – The Wrinkle Release cycle will release wrinkles from items that are clean, dry,
and only slightly wrinkled, such as clothes from a crowded closet, suitcase or items that have been
in the dryer too long after the cycle has ended. Wrinkle Release can be used with any temperature
selection.
Air Fluff – The Air Fluff cycle tumbles the load in room temperature air.
9. Start/Pause Selection Button
Press to pause and restart programs.
10. Power Button
Press once to turn your dryer on, press again to turn it off. If your dryer is left on for more than 10
minutes without any buttons being touched, the power automatically turns off.
Operating Instructions, Tips
