26_ operating Instructions, tips
Select Cycle
Option
Adjust Time – Time can be added or subtracted from the automatically set times
in the Manual Dry cycles (Time Dry, Quick Dry, or Air Fluff cycles).
To add or subtract time from the cycle, press the Adjust Time arrow pad up or
down until the desired time is displayed.
Wrinkle Prevent -Wrinkle Prevent provides approximately 180 minutes of
intermittent tumbling in unheated air at the end of the cycle to reduce wrinkling.
Press the Wrinkle Prevent button to activate this feature.
The indicator light above the pad will illuminate when Wrinkle Prevent is selected.
The load is dry, and can be removed at any time during the Wrinkle Prevent cycle.
My Cycle – Choose your favorite cycle including cycle, temp, dry level option,
etc. (See page 27 for detail.)
Rack Dry – Rack Dry is available at Time Dry cycle. Temperature will be set only
to Extra Low. (See page 28 for detail.)
Mixed Load Bell - This is an alarm that notifies the user of the time when the
average dry level is damp dry (80% dried) when the laundry contains various
types of cloth. An alarm is sounded for five (5) seconds while continuing to
perform the cycle.
This function can only be selected in the Sensor Dry course, and the dry level can
only be selected from among Normal Dry, More Dry, and Very Dry.
Start/Pause
selection button
Press to pause and restart programs.
Power button
Press once to turn your dryer on, press again to turn it off. If your dryer is left
on for more than 10 minutes without any buttons being touched, the power
automatically turns off.
CHILD LOCK
A function to prevent children from playing with your dryer.
Setting/Releasing
If you want to set or release the Child Lock, press both the Temp. and Time buttons
simultaneously for 3 seconds.
How to Set:
1. It can be set while your dryer is running.
2. Once you set the Child Lock function, no button, except for the Power button, will respond
until you release the Child Lock function.
3. The Child Lock indicator will be lit.
1. If the dryer is powered on again, the Child Lock function stays on.
2. To release that function, follow the instructions above.
When other buttons, except for the Power button, do not respond, check the Child Lock
indicator.
operating Instructions, tips
8
9
10
