For details of other Morphy Richards products, please see our website:
Water Spray
D
Press the water spray button ¤
and aim the spray of water at
stubborn creases. You can do
this whilst dry ironing providing
there is water in the tank. When
using the water spray it may be
necessary to push the water
spray button a few times to get
the spray pump primed.
Variable steam
E
Fill the iron with water as
described in ‘Filling’, page
4, and insert the plug into
the electrical socket.
The steam output can be varied
from low to high by moving the
variable steam switch. At low
temperatures, the variable
steam switch should also be set
to low. The higher the
temperature, the higher variable
steam switch can be set.
The steam facility should only
be used on garments which are
suitable for ironing at 2 - 3-dot
and MAX settings.
Economy / Eco steam
setting
(certain models only) E
This iron provides you with two
specific steam levels, the first
position is an economy or “Eco”
setting which delivers a specific
amount of steam adequate for
most tasks. Move the variable
steam switch across until it
aligns with the green indicator
line. A second setting is
available to handle difficult jobs
such as stubborn creases. The
“Eco” or economy setting can
be used at the 2-3 dot and MAX
temperature levels, high steam
is suitable for 3-dot and MAX
levels only.
Steam boost
F
Press the steam boost
button ⁄ to obtain a
boost of extra steam for
ironing out creases in
heavy material such as
denim etc.
The shot of steam can be used
whilst dry ironing, providing
there is water in the tank, and
the temperature dial is set within
the steam range.
Do not use shot of steam at
temperatures below the steam
range shown on the temperature
dial.
NOTE: For optimum steam
quality, do not operate the shot
more than three times in
succession.
Vertical steam
Hold the iron in a vertical
position between 1cm and 2cm
away from the item G. Press
the steam boost button ⁄, this
will create vertical steam.
This feature is especially useful
for removing creases from
hanging clothes, curtains, wall
hangings, etc.
NOTE; For optimum steam
quality, do not operate the shot
more than three times in
succession.
No drip system
(certain models only)
The no drip system is designed
to prevent water escaping from
the soleplate fl when the iron is
too cold.
During use, this feature may
emit a loud click, particularly
during heat-up or whilst cooling
down. This is perfectly normal
and indicates that the system is
functioning correctly.
Auto shut-off
(certain models only)
If your iron is fitted with the auto
shut-off function, it will
automatically shut down after a
set period.
If the iron is left unattended in
the horizontal position, it will
shut down after 1 minute.
If it is left in the vertical position,
it will shut down after 8 minutes.
F
⁄
D
¤
E
Off / No steam
Economy / Eco steam setting
(certain models only)
High steam setting
G
