MOTOR, PUMP AND IDLER ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 40112301 SHIELD, MOTOR 10 1
2 40046701 SCREW, #10X7/16 ID HX 10 2
3 27001215 MOTOR W/PULLEY (2 SPEED) 10 1
4 40053701 POST, ISOLATOR 10 4
5 40053801 MOUNT, MOTOR UPPER 10 4
6 40045001 IDLER PULLEY ASSEMBLY 10 1
7 40015502 BRACKET,MOTOR MOUNT 10 1
8 40054301 MOUNT, MOTOR LOWER 10 4
9 40095101 LOCKNUT, 10-32 10 4
10 40061401 SPRING, IDLER LEVER 10 1
11 23748 RING, RETAINING 10 1
12 27001028 IDLER LEVER ASSEMBLY 10 1
12 40038901 SCREW, 1/4-20 Note: IDLER BRACKET TO MOTOR BRACKETNOT SHOWN IN CATALOG 10 1
12 27001225 NUT, JAM MID LOCK 1/4-20 Note: IDLER BRACKET TO MOTOR BRACKETNOT SHOWN IN
CATALOG
10 1
13 40063701 SCREW, 10-16X1.75 10 3
14 27001036 PUMP ASSEMBLY 10 1
15 27001006 BELT, SPIN & AGITATOR 10 1
16 52549 WASHER, 501 ID X3/4 ODX 10 2
17 Y504082 WASHER, WAVE 10 1
18 40054701 WASHER 10 1
19 40038901 SCREW, 1/4-20 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
