TOP AND CABINET PARTS
2
For Models: MHWZ400TQ00, MHWZ400TB00
(White) (Black)
W10140755
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10117443
Use & Care Guide
W10118956
Tech Sheet
W10118989
Energy Guide
W10112913
Quick Start Guide
2 Top
8540716 White
W10128645
Black
3 Cabinet
8540548 White
W10117456
Black
4 Panel, Front
W10112948
White
W10117457
Black
5 Toe Panel
8540813 White
W10112981
Black
6
W10121009
Foot, Leveling (4)
7 487576 Washer, Plastic
8 3359452 Nut, Lock (4)
9 8518891 Rivet
10 8540580 Panel, Rear
11 8540581 Brace, Transport
12 8540199 Bolt, Shipping (4)
13 Hose, Water Inlet
8571377 Blue Coupler
8571378 Red Coupler
14
W10029820
Cord, Power
15 8540540 Motor Control Unit
16 8540974 Brace, Rear
17 8540093 Clamp, Tube
Transportation
18
W10114608
Hose, Drain
19 8540607 Retainer,
Hose Outlet
20 238614 Bumper (2)
21
W10015090
Screw, 8−18 x 5/8
22 8540230 Filter,
Interference
23 8540224 Switch, Pressure
24 8540294 Hose, Pressure
Switch
25 8540479 Screw, Grounding
26 8540268 Cover, Transport
27 8540021 U−Bend,
Drain Hose
28
W10085220
Microswitch (2)
29 8540728 Sleeve,
Cord Support (2)
30 8540727 Screw, 3 x 8 mm
31 8540329 Screw
32 8540720 Brace, Top
(Includes Item 33)
33 8283273 Damper, Brace
34 2161302 Sleeve, Pressure
Switch Hose
35 3347868 Cable Tie
36 16123 Washer, Water
Inlet Hose (4)
1−1/16 x 5/8
37 8540290 Harness Channel,
Top Rear
38 8540288 Harness Channel,
Side Front
39 8540289 Harness Channel,
Side Rear
40
W10110676
Strain Relief,
Power Cord
41 8540644 Bracket, Spring
