Maytag MFW9800TQ0 Washer User Manual



CONTROL PANEL PARTS
6
For Models: MFW9800TQ0, MFW9800TK0
(White) (Pacific Blue)
W10157670
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
W10163309
White
W10163310
Pacific Blue
2 8182150 User Interface
3
W10163302
Button, Power
4 8182183 Pal−nut
5
W10163305
Button Set,
Left
6
W10163304
Button Set,
Middle
7
W10163303
Button Set,
Right
8
W10163306
Button Set,
Start
9 8182224 Brace, Front Top
10 8181640 Channel, Water
11
W10137702
Microcomputer,
Machine Control
12 8181756 Screw
13 8182212 Harness, Wiring
(Main)
14 8182171 Bezel, Knob
15
W10163300
Overlay, Door
16 8183059 Medallion
17
W10163301
Knob, Control
18 Endcap, Left
8182599 White
W10163314
Pacific Blue
19 Endcap, Right
8182600 White
W10163315
Pacific Blue
20 Handle, Drawer
(Includes Item 18)
W10163312
White
W10163313
Pacific Blue
