BASE
No. Part No. Description
Section:
Series Qty
1 22004376 SPRING, MOTOR PIVOT 10 1
2 21001516 MOTOR & PULLEY ASSY. 10 1
3 22002721 SHIELD, MOTOR 10 1
- 22003438 SLEEVE, PUMP (ATL) 16 1
4 21001732 PUMP 10 1
5 25-7833 SCREW Note: SCREW, MOTOR/BASE 10 2
6 25-7834 WASHER Note: WASHER, MOTOR/BASE SCREW 10 2
7 33-9946 ISOLATOR, MOTOR 10 2
8 35-3570 WASHER, MOTOR PIVOT Note: WASHER, PIVOT 10 2
9 21001366 PLATE, MOTOR 10 1
- 35-2065 PAD, MOTOR PLATE 10 1
10 35-3646 ISOLATOR, MOTOR PLATE 10 3
- 22004348 SLIDE, MOTOR PIVOT Note: FOOT SLIDE, ISOLATOR 10 1
11 25-7831 SPACER Note: SPACER, MOUNTING 10 2
12 22004297 PULLEY 21 1
12 21001506 PULLEY, MOTOR-60 HZ 10 1
13 22002853 CLAMP, HOSE Note: CLAMP, HOSE 10 2
14 35-3571 SLIDE, MOTOR PIVOT Note: SLIDE, MOTOR 10 2
15 33-9967 WASHER, MOTOR ISOLATOR 10 2
16 25-7047 WASHER, FLAT 10 2
17 25-7325 NUT, MOTOR PLATE ASY TO MOTOR Note: NUT, MOTOR PLATE ASSEMBLY 10 2
18 21001598 SPRING, SUSPENSION 10 6
19 21001166 HOOK, SUSPENSION SPRING 10 3
20 21001754 BAR, STABILIZER 10 1
21 35-2046 BRACKET, STABILIZER 10 2
22 35-2052 PIN, STABILIZER 10 2
23 35-3020 FOOT PAD ASSY. (REAR) Note: FOOT & PAD ASSEMBLY (REAR) 10 2
24 31001041 SCREW Note: SCREW, BRACKET/BASE 10 6
25 22002841 BASE 10 1
26 25-7845 SPEEDNUT Note: SPEEDNUT, MOTOR 10 2
27 22003285 HOSE, TUB TO PUMP 15 1
27 35-3584 HOSE, TUB TO PUMP 10 1
28 35-3507 FOOT & PAD ASSY Note: FOOT & PAD ASSEMBLY (FRONT) 10 2
29 N 25-7951 WASHER, SUSPENSION HOOK 10 3
30 22002709 BELT, DRIVE 10 1
31 25-7830 SPACER 10 2
32 22002239 CLIP, LOWER FRONT PANEL 10 2
- 22002966 U-NUTS, TINNERMAN (FRT PNL) 10 2
33 22002782 PAD, FOAM (SOUND DAMPENER) 10 8
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
