DOOR & FRONT PANEL
No. Part No. Description
Section:
Series Qty
1 22003243 DOOR, OUTER W/MEDALLION (BSQ) 10 1
1 22003325 TAG, ENERGY (LED) 10 1
2 22002990 VENT TUBE ASSEMBLY 10 1
3 22003269 DOOR, LOCK HOOP ASSEMBLY 10 1
4 22003279 DOOR, INNER (BSQ) 10 1
5 22002038 CLIP, DOOR (DOUBLE) 10 4
6 22002039 CLIP, DOOR (SINGLE) 10 2
7 22002104 WIREFRAME Note: REMOVED AT SERIES C6 PER ECN EL43377 10 1
8 22002356 SPRING, PLATE Note: REMOVED AT SERIES C6 PER ECN EL43377 10 4
9 22002094 PLATE Note: REMOVED AT SERIES C6 PER ECN EL43377 10 1
10 22002007 SCREW Note: REMOVED AT SERIES C6 PER ECN EL43377 10 2
11 22003075 GROMMET, VENT TUBE 10 1
12 22002798 HINGE, DOOR 10 2
12 22002612 COVER, HINGE (BSQ) Note: COVER, HINGE (BSQ) 10 2
13 22002062 SCREW Note: SCREW, HINGE 10 4
14 33002351 SCREW (#8-18 OUTER DOOR (BSQ) Note: SCREW, OUTER DOOR (BSQ) 10 6
15 22001995 SCREW Note: SCREW, FRONT PANEL CLIP 10 2
15 22002305 INSULATION, FRONT PANEL 10 1
15 22002239 CLIP, LOWER FRONT PANEL 10 2
15 22002663 PANEL, FRONT (BSQ) Note: PANEL, FRONT (BSQ) 10 1
15 22004428 SEAL, EXPORT 10 1
16 22002012 SCREW, HINGE Note: SCREW, HINGE 10 4
17 22002244 CLIP, GROUNDING 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
