TOP AND CABINET PARTS
2
For Model: LCR7244HQ1
(White)
3968450
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT3935938
Installation
Instructions
LIT3967363
Use & Care Guide
LIT3969052
Energy Guide
LIT3968795
Wiring Diagram
Tech Sheet
LIT3968468
English
LIT3968467
French
2 3967826 Cabinet
3 3935590 Lid
4 3935130 Pin, Wheel
5 19119 Bumper, Lid
Hinge
6 3934035 Screw, Top To
Cabinet (3)
7 3935351 Hinge, Lid (R.H.)
8 3351355 Screw, Lid Hinge
Mounting (4)
9 3935634 Screw
10 3428525 Cover, Pump
11 358684 Strike, Lid Switch
12 3934872 Caster (4)
13 3934148 Screw
14 3429705 Protector, Edge
15 3935737 Switch, Lid
16 3935602 Screw, Lid Switch
17 3935198 Bracket−Cabinet
To Top
18 3935352 Hinge, Lid (L.H.)
19 3935442 Bumper
20 3430186 Rivet
21 3935739 Bearing−Hinge (RH)
22 3935889 Bearing−Hinge(LH)
23 21097 Pad, Hinge
24 3400061 Screw
25 3935201 Extrude−Top (2)
26 3429189 Screw (4)
27 3430058 Panel−Cabinet
28 3429823 Rivet−Plastic (2)
29 Gusset
3935128 Lower (L.H.)
3935129 Lower (R.H.)
30 3968521 Top
