Printed in February 2008 SS-5007
WM3988HWA
TYPE
Front Loader
Design Look Front Control
Intelligent Electronic Controls with Dial-A-Cycle
™
Drying System Ventless Condensing
CAPACITY
Total Capacity* 4.2 cu.ft. (IEC)
Dry Linen Capacity >10.1kg
ENERGY
Energy Star
PROGRAMS
9 Wash Programs SteamFresh
™
, Sanitary (158°F), Bulky/Large,
Perm Press, Cotton/Normal, Delicates,
Hand Wash/Wool, Speed Wash, Allergiene
™
5 Wash/Dry Programs Sanitary, Perm Press, Cotton/Normal,
Allergiene
™
, Speed Wash
5 Wash/Rinse Temperature Levels Extra Hot/Cold, Hot/Cold, Warm/Warm,
Warm/Cold, Cold/Cold
5 Spin Speeds
Extra High (1320 RPM Max), High (1150/1000 RPM),
Medium (1000/950/600 RPM),
Low (950/600/400 RPM), No Spin
4 Dry Times 120 min, 90 min, 60 min, 30 min
No. of Water Levels Automatically adjusts to size of load
No. of Soil Levels 5
Options Prewash, Rinse & Spin, Extra Rinse, Stain Cycle,
Water Plus, Drum Light, Tub Clean, SpinSense
™
,
Delay Wash up to 19 Hours, Steam, Language Selection
FABRIC CARE FEATURES
SteamWash
™
System
SenseClean
™
Sensor Dry
RollerJets
™
& Forced Water Circulation
CONVENIENCE FEATURES
4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup),
Bleach, Softener
End of Cycle Beeper
Child Lock
Self Diagnosis
Tub Light White LED
Auto-Balancing
Auto Suds Removal
Forced Drain System
Remaining Time Display/Status Indicator
Water Heater
TrueSteam
™
Generator
Leveling Legs 4 Adjustable
LoDecibel
™
Quiet Operation
MOTOR AND AGITATOR
Motor Type / Motor Speed / Axis Direct Drive / Variable / Horizontal
MATERIALS AND FINISHES
NeveRust
™
Stainless Steel Drum
Easy Loading TilTub
™
Cabinet Top Porcelain
Transparent Glass Window Door
Door Rim Chrome
Cabinet Painted Steel
Control Panel Plastic
Colors White
POWER SOURCE
Ratings/Electrical Requirements UL Listed/120V, 60Hz, 12 Amps
Type Electric
DIMENSIONS
Product (WxHxD) 27" x 38 11/16" x 29 3/4"
(51"D with door open)
Weight (lbs): Net / Gross 201 / 227
OPTIONS
Pedestal WDP3W (Drawer with Handle)
WARRANTY
1 year parts and labor
2 years on the control board
7 years on the motor
Lifetime on the drum
UPC CODE
WM3988HWA 048231 009560
WDP3W 048231 008556
Design and specifications are subject to change without notice.
©2008 LG Electronics U.S.A., Inc., Englewood Cliffs, NJ
All Rights Reserved. LG Design and Life's Good are trademarks of LG Electronics Inc.
ASTHMA AND ALLERGY FRIENDLY and ASTHMA AND ALLERGY FRIENDLY LOGO are Certification
Marks and Trademarks of ALLERGY STANDARDS LIMITED. The ASTHMA AND ALLERGY FOUNDATION
OF AMERICA is a Registered Trademark of AAFA.
All other trademarks are property of their respective owners.
* Per IEC 60456 washes the equivalent of 4.2 cu.ft.
conventional agitator washer.
WASHER/DRYER COMBO
LG ELECTRONICS INC.
1000 Sylvan Ave., Englewood Cliffs, NJ 07632
800.243.0000 LGusa.com
Full Size All-in-One Washer and Dryer
SteamFresh
™
LG's innovative SteamFresh
™
cycle makes it possible for
you to refresh and reduce wrinkles in up to 5 garments at
one time. Running late for work with no time to iron? Load
a cotton blend shirt into the SteamWasher
™
and select the
SteamFresh
™
cycle. You'll be ready to go in just 20 minutes.
Allergiene
™
Allergiene
™
cycle is proven to reduce certain allergens such
as house dust mites and domestic animal dander.
Intelligent Electronic Controls
with Blue LCD Display
Intuitive controls allow you to 'set it and go'. The large LCD
display provides instructions and diagnostics while keeping
you updated on the cycle status and time remaining.
Direct Drive
Power is delivered right to the drum from the motor
without belts, resulting in a highly durable, powerful and
quiet washing machine.
SenseClean
™
System
The water level and wash time are set automatically
based on the weight and size of each load for optimal
washing care.
RollerJets
™
& Forced Water Circulation
Clothes glide over the RollerJets
™
while sprinklers encourage
the removal of soil, reducing pilling, fraying, and snags for
longer lasting clothing.
Sanitary Cycle
Get tough stains and bacteria out of dirty clothes with this
special cycle that boosts water to 158°F.
LoDecibel
™
Quiet System
Anti-vibration motor and one-piece cabinet structure
reduce unnecessary noises.
