Hoover DYH 9913NA1X Clothes Dryer User Manual



EN 6
DRAIN HOSE : FITTING INSTRUCTIONS
WARNING! Switch off and remove the
tumble dryer plug from the electricity supply
before carrying out any work.
Fit he s Follows:t Hose a
1.
slowly to the right side.
2.
pipe
right-hand side of the
machine (see the
picture). A grey hose
connects to the bridge
at the left hand side of
the machine. Using
pliers, remove the pipe
retaining clip from the
bridge.
3. Pull the hose off the
bridge connection.
Flip the machine
The waste water
is situated at the
4. black
hose from the kit,
(using the connector
a n d p i p e c l i p s
supplied), to the hose
removed from the
bridge connection.
5. Once the machine is
in place, check the
bottom to ensure that
the new hose does not
kink when pushing the
tumble dryer into
position.
6. Connect the new
drain hose to the waste
Water pipe.
7. Connect to the
mains electricity
supply.
Caution: If the product
is in different side, wait
at least 4 hours before
switching on so that the
oil can flow back into
th e co mpr esso r.
Failure to do this could
result in damage to the
compressor.
Attach the
To avoid emptying the water container after
each drying cycle, the water can be
discharged directly to a waste water drain pipe
(the same drainage system as household
sinks). Water Bye-Laws prohibit connection to
a surface water drain. The waste water drain
pipe should be located adjacent to the tumble
dryer.
The kit consists of:1 hose and 1 tap.
there is a risk of frost occurring. At temperature
around freezing point the product may not be
able to operate properly: there is a risk of
damage if the water is allowed to freeze in the
hydraulic circuit (valves, hoses, pumps).
For a better product performance the ambient
room temperature must be between +2°C and
+35°C.
Do not install the product in a room where
DRAIN HOSE KIT: FITTING INSTRUCTIONS
