2
Installation Instructions
INSTALL THE PEDESTAL
TO THE WASHER OR DRYER
Place the pedestal against the bottom
of the unit. Check to be sure the drawer
front is at the front of the unit.
Align the holes in the pedestal with
the holes in the bottom of the unit.
Use a Phillips screwdriver to install
the 4 screws through the pedestal
and into the unit—do not tighten.
Slide the pedestal toward the unit,
until it is aligned front to back. Use an
8 mm socket wrench to securely tighten
the screws.
C
B
A
3
PREPARE THE PEDESTAL
Pull the
drawer out
as far as it
will go.
Remove
screws from
drawer slides.
Slide drawer
out of the base
and set aside.
FOR DRYERS ONLY:
Locate the 4 support pads from the parts
package. Each pad has 2 protrusions that
fit into the holes on top of the pedestal.
Press the rubber pads into each set of
corner holes on the top of the pedestal
as shown.
NOTE: The support pads should be installed
on the dryer only. DO NOT INSTALL THESE
PADS ON THE WASHER PEDESTAL.
C
B
A
2
