Avanti W798SS Washer User Manual



8
? Put your laundry into the washer evenly. Uneven laundry may cause noise or vibration.
? Don’t use excessively hot water (50°C or more). Plastic parts may be deformed or damaged.
Also, clothing may be deformed or bleached.
? Before washing, check all pockets. If nails or pins remain in pockets, they may damage the
washer or clothes.
? Never splash water on the control panel.
? Plug the washer into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
SELECTING A LOCATION
Before you install the portable washer, select a location with the following
characteristics:
? A hard level surface (if the surface is uneven, see Adjusting The Adjustable
Foot).
? Away from direct sunlight. Direct sunlight may affect the acrylic coating,
plastic and electrical components.
? Adequate ventilation.
? Away from sources of heat such as coal or gas. Make sure that the
washing machine does not stand on its power cord. Ventilation openings
must not be obstructed by carpeting when the portable washer is installed
on a carpeted floor.
ADJUSTING THE ADJUSTABLE FOOT
If the floor is uneven adjust the adjustable foot (do not insert pieces of wood,
or any other objects under the feet).
Loosen the adjustable foot by turning the level a djustable knob with your
hand until it is at the desired height.
Tighten the adjustable foot by turning the level adjustable knob in the
reverse direction.
Place the washer on a sturdy flat surface.
If the washer is placed on an uneven or weak surface, noise or vibration
occurs (Allowable is 1°).
For portable applications, the washing machine comes equipped with four
north/south casters that can easily be installed to assist in the movement of
the machine to and from the sink. Lay the unit on its back. Install the casters
into the bottom of the base as indicated.
Return the machine to the upright position. When the machine is positioned
for operation set the height of the adjustment foot slightly higher than the
front caster to prevent movement of the machine during wash and spin
operation.
NOTE: Not all movement will be totally eliminated, this is normal.
LOOSEN
TIGHTEN
LEVEL
ADJUSTABLE KNOB
CORRECT
INCORRECT
INCORRECT
Fixed foot
Caster
Caster
Fixed foot
Adjustable foot
Caster
Caster
Fixed foot
ADJUSTABLE FOOT
Net weigh
9
3
9
m
m
5
4
4
m
m
5
3
8
m
m
