Avanti W757 Washer User Manual



10
ADJUSTING THE ADJUSTABLE FOOT / SAFETY STOPPER
For a more efficient use of your portable washer it must be located on
a level hard stable surface.
If the floor is uneven adjust the adjustable foot (do not insert pieces
of wood, or any other objects under the feet).
Place the washer on a sturdy flat surface.
Lower (Loosen) the adjustable foot by turning the level adjustable
knob with by hand until it is at the desired height.
Raise (Tighten) the adjustable foot by turning the level adjustable
knob in the reverse direction.
If the washer is placed on an uneven or weak surface, noise or
vibration occurs (Allowable is 1°).
For portable applications, the washing machine comes equipped
with four (4) single direction casters that can easily be installed to
assist in the movement of the machine to and from the sink.
Lay the unit on its back.
Install the casters into the bottom of the base as indicated in the figure shown on the right.
Return the machine to the upright position.
When the machine is positioned for operation/use set the height of the adjustment foot /
safety stopper slightly higher than the front caster to prevent movement of the machine during
wash and spin operation.
NOTE: Not all movement will be totally eliminated, this is normal.
INSTALLING THE NOISE DAMPER PLATE
