M411988
13
Front Panel Assembly
(Prior to Serial No. DTCK0728885ZH)
REF PART NO. DESCRIPTION COMMENTS
1 431323* Front Panel – Upper Painted
431169 Front Panel – Upper Stainless Steel
2 M401223 Catch Included with Front Panel
3 M400003 Rivet Included with Front Panel
4 430640P Microprocessor
5 430228 Coin Chute
6 430452 Coin Chute Bracket Left
430451 Coin Chute Bracket Right
7 430460 Plug
8 430489 Rivet
9 430382 Coin Vault Bracket
10 430449 Screw
11 431324* Front Panel – Lower Painted
431170 Front Panel – Lower Stainless Steel
12 M400972 Clip
13 430548 Coin Vault Shadow Box
14 431000* Hinge Bracket Painted, included with Front Panel
431044 Hinge Bracket Stainless Steel, included with Front Panel
15 M410762 Rivet Included with Front Panel
16 430638 Seal Included with Front Panel
17 431326 Microprocessor Shadow Box
18 430995 Coin Drop Shadow Box
* Add letter to designate color: L - Almond W - White V - Orange K - Red
B - Battina Green H - Harvest Gold X - Electric Blue P - Turquoise
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
