Maytag W10160250A Clothes Dryer User Manual



25
*Temperature and Timed Cycle Adjust are selectable only for the Custom Refresh Cycle.
NOTE: The Custom Refresh cycle has a minimum dry time of 15 minutes and a maximum
dry time of 40 minutes. Only the Medium and High temperature settings can be used for
the Custom Refresh cycle.
Timed Cycles
Use Timed Cycles to select a specific amount of drying time and a drying temperature. When
a Timed Cycle is selected, the Estimated Time Remaining display shows the actual time
remaining in your cycle. You can change the actual time in the cycle by pressing the Timed
Cycle Adjust up or down arrows. See “Changing Cycles, Modifiers and Options.”
NOTE: Timed Cycles may also be used with the dryer rack. See “Drying Rack Option.”
Timed Dry
Use this cycle to complete drying if items are still damp after a Sensor Dry Cycle. Timed Dry
is also useful for drying heavyweight and bulky items, such as bedspreads and work clothes.
Lightweight garments, such as exercise wear, can be dried using Timed Dry on a low
temperature setting. Timed Dry can also be used with the Drying Rack.
Modifiers
Sensor Dry Cycle Modifiers
Use the DRYNESS button to select dryness levels for the Sensor Dry Cycles. Press DRYNESS
until the desired Dryness setting illuminates.
The preset dryness setting is Normal when a Sensor Dry Cycle is selected. You can select a
different dryness level, depending on your load, by pressing Dryness and choosing More,
Normal, Less or Damp. Selecting More, Normal, Less or Damp automatically adjusts the
dryness level at which the dryer will shut off. Once a dryness level is set, it cannot be changed
without stopping the cycle.
NOTE: Dryness Level selections cannot be used with the Timed or Steam Cycles.
Timed Cycle Modifiers
Use the TEMPERATURE button to select temperatures for the Timed Cycles. Press TEMP until
the desired temperature setting illuminates.
NOTE: Temperature modifiers cannot be used with the Sensor Dry Cycles.
Steam Refresh Preset Cycle Settings
Timed Cycles
Load Type
Default Temperature* Default Time
(Minutes)*
RAPID REFRESH Small Load
Helps to smooth out wrinkles and
reduce odors from loads consisting of
one to four dry items.
Medium 15
CUSTOM REFRESH
Helps to smooth out wrinkles in loads
left in the dryer for an extended
period.
Medium 20
Timed Preset Cycle Settings
Timed Cycles
Load Type
Default
Temperature
Default Time
(Minutes)
TIMED DRY
Heavyweight, bulky items, work
clothes
High 40
