F. ELECTRICAL INFORMATION
1. Electrical Requirements
It is your responsibility to have
ALL electrical connections made by a properly licensed and competent
electrician to assure that the electrical installation is adequate and conforms to local and state regulations or
codes. In the absence of such codes,
ALL electrical connections, materials, and workmanship must
conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST
EDITION or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
IMPORTANT: Failure to comply with these codes or ordinances, and/or the requirements stipulated
in this manual can result in personal injury or component failure.
NOTE: Component failure due to improper installation will VOID THE WARRANTY.
IMPORTANT: Each circuit must be connected to an independently protected branch circuit.
IMPORTANT: USE ONLY COPPER CONDUCTOR CABLE of proper ampacity and insulation in
accordance with electric codes for making service connections.
NOTE: The use of aluminum wire will VOID THE WARRANTY.
IMPORTANT: A separate circuit servicing each dryer must be provided.
2. Electrical Service Specifications
a. Electric Service
1) Gas Models ONLY
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is
affixed to the upper left area of the inner back panel.
IMPORTANT: USE ONLY COPPER CONDUCTOR CABLE of proper ampacity and insulation in
accordance with electric codes for making service connections.
NOTE: Component failure due to improper voltage application will VOID THE WARRANTY.
